High and low voltage online management system
TIME:2023-10-30

High and low voltage online management system

A professional technical team, reliable and stable component selection, compensation power factor not less than 0.96, and solutions for heavy-duty starting, etc

This system adopts a fully Chinese interface, which is simple and convenient to operate; Stable and reliable operation; The system has a system diagram display, simulation diagram display, and network structure diagram display; The system provides a friendly human-computer interaction interface, where all operations can be performed and has remote display function.

Station control management

The station control management layer is a direct window for human-machine interaction for the management personnel of the power monitoring system. It mainly refers to industrial control computers, displays, UPS, etc. located in the duty room.

Network communication layer

The communication layer is mainly composed of collectors and bus networks. The main functions of the collector are to monitor on-site intelligent instruments, comprehensive protection devices, transformer temperature controllers, and DC screens; The main function of the bus network is to achieve data exchange, ** the management of the distribution system centralized, informationized, and intelligent, improving the safety, reliability, and stability of the distribution system, and achieving the goal of unmanned operation.

On site equipment layer

The on-site equipment layer is a data acquisition terminal, mainly composed of a transformer temperature controller, a comprehensive protection device, a multifunctional instrument, and a DC screen. It is connected to a communication server through a shielded twisted pair RS485 interface and a MODBUS communication protocol bus. The communication server then reaches the monitoring host in the distribution room for networking, achieving remote monitoring.
