Ideal Applications:

✓ Large-scale mining & quarrying

✓ Hard rock processing

✓ Environmentally sensitive sites

✓ Mobile crushing operations

1. Superior Crushing Capability Equipped with advanced cone crushing technology delivering 40% higher processing capacity, specially optimized for medium-to-hard materials. Features 8:1 crushing ratio with uniform output size (adjustable 5-50mm discharge) and 50-400TPH production capacity (model dependent). Hydraulic CSS adjustment ensures precise grading control.

2. Intelligent Mobility System Tracked chassis provides all-terrain accessibility with 360° zero-radius steering and ≤5m turning capability. Achieves 15° slope operation with 30-minute rapid deployment. Built-in metal detection and automatic protection system (0.5s response time) safeguards equipment integrity.

3. Eco-Smart Operation Complies with Stage III emission standards (electric version available) while maintaining <72dB low-noise operation. Energy-saving design reduces power consumption by 25% with optimized crushing chamber that increases yield by 30%. Pre-screening module enhances material classification efficiency by 40%.
