When the cone crusher is working, the electric motor drives the eccentric sleeve to rotate through an elastic coupling, transmission shaft, and bevel gear. The axis of the crushing cone moves in a rotary motion under the force of the eccentric sleeve,causing the crushing wall and the rolling white wall to approach and move away from each other. 360 ° continuously compresses and impacts the materials in the crushing chamber, and the crushed materials are discharged from the lower part.
The Wanshihengtong HPT series multi cylinder hydraulic cone crusher has the characteristics of reliable structure, high production efficiency, convenient adjustment and low cost.
Performance &characteristics
1. Adopting a fixed spindle, the equipment has strong load-bearing capacity, more compact structure, small volume, and high efficiency.
2. Install a temperature sensor at the oil return point of the horizontal axis to accurately detect the oil temperature and ensure stable operation of the equipment.
3. While thickening the cone wall, the fixing method of the lining plate is improved, ** replacement convenient and fast, and reducing maintenance costs.
4. Integrated hydraulic lubrication and unique thin oil lubrication system design greatly improve the service life of the equipment.
5. The oil circuit of the safety cylinder adopts a large diameter oil pipe and a large capacity energy storage device, which has better buffering performance and
faster response.
6. By adopting the principle of inter particle lamination design, the crushing efficiency and fine material ratio have been improved, needle like materials have
been reduced, and steel consumption of vulnerable parts has been reduced.
