The frontal crusher is an early type of crushing equipment, mainly used for coarse and medium crushing of crushed materials with a maximum compressive strength

of 320MPa, such as river pebbles, granite basalt, iron ore, limestone, quartz stone,coal grinding stone, construction waste, etc. It can be widely used in mining,smelting, building materials, highways, railways, water conservancy, and chemicalindustries.

The Wanshiheng Tongdun crusher adopts a new design structure and advanced manufacturing technology using high-end materials. By optimizing the structure and motion parameters of the crushing chamber, it ensures stable operation in various environments.

The C series European version of the frontal crusher places greater emphasis on details in design and manufacturing, using high-strength materials and high standard manufacturing processes. It has advantages such as higher structural strength, higher equipment reliability, larger crushing ratio, higher production capacity, and lower overall cost.

Performance &characteristics

1. High impact resistance and stability, convenient lubrication, and longer running time.

2. Adopting mechanical or hydraulic discharge port adjustment devices, the adjustment operation is simpler, safer, and faster, saving downtime.

3. Symmetrical "V" shaped cavity design, with large inclination angle, large stroke, and reasonable rotation speed of the shaft plate, resulting in larger feed particle

size, higher output, more uniform particle size, and reduced forehead wear.

4. Heavy duty protective plate effectively protects the rotor and its internal bearings from damage.

5. Due to the synchronous movement of the frame, motor base, and motor, the adjustable motor base achieves the adjustment of the tension of the triangular

belt, thereby extending the service life of the triangular belt.
