The impact crusher is a commonly used new type of high-efficiency crushing equipment, which has the characteristics of small volume, simple structure, high crushing ratio, low energy consumption, high production capacity, and uniform product particle size. It is widely used for material processing in metallurgical, chemical, building materials, water and electricity operations, and can adopt various configuration forms based on the type, scale, and finished material requirements of the processed raw materials.

The Wanshihengtong PF series impact crusher can be used for coarse and medium crushing of various types of ores and rocks with compressive strength not exceeding

360MPa. After crushing, the product has good particle shape and low needle and sheet content.

Performance &characteristics

1. The maximum particle size of the feed is 1000mm, with multiple cavities for uniform crushing, suitable for crushing

hard rocks, and the finished material grading is reasonable.

2. The internal and external parts withstand strong impact force, and the casing is sturdy and not deformed.

3. The new wear-resistant material has excellent quality, and the wear-resistant edge protection hammer disc, plate

hammer, impact plate, and lining plate have a longer lifespan.

4. The wear-resistant parts are fastened with bolts for easy disassembly.

5. Compact structure, strong machine rigidity, and large rotor inertia.

6. The crushing ratio is large, so the crushing process can be simplified, ** three stage crushing into two or one

stage crushing, reducing the equipment cost of the beneficiation plant.
